Admite AMD Ryzen ™ 5000 Series / 3rd Gen Ryzen ™ y 3rd Gen Ryzen ™ con procesadores gráficos Radeon ™ DDR4 sin búfer ECC / no ECC de doble canal, 4 DIMM Diseño digital de potencia doble de 12 + 2 fases con DrMOS de 50 A Diseño térmico avanzado con disipadores de calor de superficie agrandados Ranura Ultra Durable ™ PCIe 4.0 x16 Dual Ultrarrápido NVMe PCIe 4.0 / 3.0 x4 M.2 con un protector térmico Audio AMP-UP con condensadores ALC1200 y WIMA LAN de 2,5 GbE ultrarrápida con gestión de ancho de banda USB 3.2 Gen1 Type-C ™ frontal y DisplayPort y HDMI para múltiples pantallas RGB FUSION 2.0 admite tiras de LED direccionables y LED RGB Smart Fan 5 cuenta con múltiples sensores de temperatura, cabezales de ventilador híbridos con FAN STOP Q-Flash Plus actualiza el BIOS sin instalar la CPU, la memoria y la tarjeta gráfica IO Shield preinstalado para una instalación fácil y rápida Especificaciones: Procesador AMD Socket AM4, support for: AMD Ryzen™ 5000 Series/ 3rd Gen Ryzen™ and 3rd Gen Ryzen™ with Radeon™ Graphics Processors (Por favor, acuda a "lista de soporte de CPU" para más información.) Chipset AMD B550 Memoria 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory 3rd Gen AMD Ryzen™ Processors: Support for DDR4 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200/2933/2667/2400/2133 MHz memory modules 3rd Gen AMD Ryzen™ with Radeon™ Graphics processors: Support for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200/2933/2667/2400/2133 MHz memory modules Arquitectura de memoria Dual Channel Soporte para módulos de memoria ECC Un-buffered DIMM 1Rx8/2Rx8 Soporte para módulos de memoria non-ECC Un-buffered DIMM 1Rx8/2Rx8 Soporte para módulos de memoria Extreme Memory Profile (XMP) (Por favor diríjase a la "Lista de memorias soportadas" para más información.) Gráfica Integrada Integrated in the 3rd Generation AMD Ryzen™ with Radeon™ Graphics processors: 1 x DisplayPort, supporting a maximum resolution of 5120x2880@60 Hz * Support for DisplayPort 1.4 version, HDCP 2.3, and HDR. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version, HDCP 2.3, and HDR. Maximum shared memory of 16 GB Audio Realtek® ALC1200 codec Audio de alta definición 2/4/5.1/7.1-channel Soporte para salida S / PDIF LAN Realtek® 2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit) Zócalos de Expansión 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU: - 3rd Generation AMD Ryzen™ processors support PCIe 4.0 x16 mode - 3rd Generation AMD Ryzen™ with Radeon™ Graphics processors support PCIe 3.0 x16 mode * Para un rendimiento óptimo, aunque sea con una única tarjeta gráfica PCI Express instalada, asegúrese de conectarla en la ranura PCIEx16. 1 x PCI Express x16 slot (PCIEX2), integrated in the Chipset: - Supporting PCIe 3.0 x2 mode 1 x PCI Express x16 slot (PCIEX1_2), integrated in the Chipset: - Supporting PCIe 3.0 x1 mode 1 x PCI Express x1 slot (PCIEX1_1), integrated in the Chipset: - Supporting PCIe 3.0 x1 mode Interfaz de almacenamiento 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs: - 3rd Generation AMD Ryzen™ processors support SATA and PCIe 4.0 x4/x2 SSDs - 3rd Generation AMD Ryzen™ with Radeon™ Graphics processors support SATA and PCIe 3.0 x4/x2 SSDs 1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs: - Supporting SATA and PCIe 3.0 x4/x2 SSDs 4 x SATA 6Gb/s connectors, integrated in the Chipset: - Soporta RAID 0, RAID 1, y RAID 10 USB Chipset+USB 2.0 Hub: 4 x puertos USB 2.0/1.1 disponible a través de los conectores USB internos de la placa base Chipset: 1 x USB Type-C™ port with USB 3.2 Gen 1 support, available through the internal USB header 1 x USB 3.2 Gen 1 port on the back panel 2 x USB 3.2 Gen 1 ports available through the internal USB header 2 x USB 2.0/1.1 ports on the back panel CPU: 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel 2 x USB 3.2 Gen 1 ports on the back panel Conectores Internos E/S 1 x conector de alimentación principal ATX 24-pin 1 x conector de alimentación ATX 12V 8-pin 2 x conectores M.2 Socket 3 4 x conectores SATA 6 Gb / s 1 x conector del ventilador de la CPU 1 x conexión del ventilador para refrigeración por agua 3 x conector del ventilador del sistema 1 x CPU cooler LED strip/RGB LED strip header 2 x Addressable LED strip headers 2 x RGB LED strip headers 1 x conector del panel frontal 1 x conector de audio en el panel frontal 1 x USB Type-C™ port, with USB 3.2 Gen 1 support 1 x USB 3.2 Gen 1 header 2 x conectores USB 2.0/1.1 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only) La función TPM es opcional según las diferentes políticas locales 1 x Clear
