Model Number Q500-DGNN-S00 Exterior Color 3x set: Mint, Pink, Cream Materials - Exterior Steel, Plastic, Tempered Glass Materials - Left Side Panel Grey TG + Steel Dimensions (L x W x H) 406 x 231 x 415mm (Incl. Protrusions), 380 x 231 x 381mm (excl. Protrusions) Volume 33.44L (excl. Protrusions) Motherboard Support ITX, Micro ATX, ATX, E-ATX (Width up to 296mm w/ SFX PSU, up to 273 w/ ATX PSU) Expansion Slots 7 3.5" Drive Bays 4 2.5" Drive Bays 3 I/O Panel - USB Ports 2x USB 3.2 Gen 1 Type A, 1x USB 3.2 Gen 2 x 2 Type C I/O Panel - Audio In / Out 1x 3.5mm Combo Pre-installed Fans - Rear 1x 120mm (1800 RPM) SF ARGB White PWM Fan Support - Front 1x 120/140mm (x2 if PSU is mounted in bottom) Fan Support - Top 2x 120/140mm Fan Support - Rear 1x 120mm Fan Support - Bottom 2x 120/140mm Fan Support - Left side 2x 120/140mm Radiator Support - Front 120mm, 140mm, (240/280mm w/ PSU in bottom) Radiator Support - Top 120mm, 140mm, 240mm, 280mm, (280mm can be used within 53mm thickness) Radiator Support - Rear 120mm Radiator Support - Bottom 120mm, 140mm, 240mm, 280mm Radiator Support - Left side 120mm, 140mm, 240mm, 280mm Clearance - CPU Cooler 164mm-172mm (Remove the water cooling bracket) Clearance - PSU 173mm to first GPU slot, 216 maximum space (w/o cable management space), 332mm space mounted in bottom (w/o cable management space) Clearance - GFX 365mm Cable Routing - Behind Motherboard Tray 29-32mm Handle Mint x 1, Grey x 1 Gem Mini Grey x 1 Accessory Hook x 2 Dust Filters Front, Top, Bottom, Right side Power Supply Support SFX-L, SFX, ATX Series QUBE Series Size Mid Tower
